✔ 9mm Insulated shaft sealed potentiometer
✔ Width: 9.5mm
✔ Suitable for car amplifier volume control
✔ RoHS compliant & High Quality
✔ Small volume, structural diversification
✔ Sealed type for durability
• Circuit type: SPST
• Rated Power: 1A 16V DC
• Switching torque: 500gf.cm max
• Switching angle: 40° max
• Operating life (no load): 30,000 cycles
• Operating life (with load): 30,000 cycles
• Contact resistance: 100mΩ max
• Insulation resistance: 100mΩ max min. 250V DC
• Total rotational angle: 300°±5°
• Rotational torque: 10-150gf.cm
• Click torque: 60-400gf.cm
• Rotational stopper strength: MIN 3Kgf
• Key Push-pull strength: MIN 8Kgf
• Terminal strength: 5N for 1 minute
• Total resistance: 100Ω-3MΩ
• Resistance tolerance: ±20% to ±30%
• Rated power: 0.05W
• Max operating voltage: 50V AC / 10V DC
• Insulation resistance: 100KΩ min. 205V DC
• Voltage proof: 300V AC for 1 minute
• Operating life: 15,000 cycles
Frequently Asked Questions
1. What are the primary applications for the RV97C2GS potentiometer?
It is ideally suited for car amplifier volume control, audio amplifiers, musical instrument amplifiers, guitar effectors, mixers, and various professional instruments.
2. What is the rotational life expectancy of this product?
The potentiometer features an operating life of 15,000 cycles, while the integrated switch is rated for 30,000 cycles under both load and no-load conditions.
3. Is the RV97C2GS compliant with environmental standards?
Yes, the product is fully RoHS compliant, ensuring it meets international standards for hazardous substance restrictions.
4. What is the total rotational angle of the shaft?
The total rotational angle is 300° with a tolerance of ±5°, providing a wide range for precise adjustment.
5. Can this potentiometer handle both AC and DC voltages?
Yes, it has a maximum operating voltage of 50V AC and 10V DC, making it versatile for different circuit designs.
6. What type of resistance scales are available?
The RV97C2GS supports both Logarithmic (Log) and Linear resistance change scales to suit different audio and electrical requirements.
