DG263-7.5-03P-11-00Z(H) Terminal Block Connector, Socket, Integrated Circuit.
This high-performance terminal block is designed for robust electrical connections in industrial applications. Featuring a 45° connection direction and a spring-cage connection method, it ensures secure and stable wiring for various electronic circuits. The modular design supports PCB welding and is optimized for both manual and wave soldering processes.
| Processing & Connection Capacity | |
| Process | Wave soldering / manual soldering |
| Conductor cross section solid | 0.2~6mm² |
| Conductor cross section flexible | 0.2~6.0mm² |
| AWG | 24~10AWG |
| Strip length | 12mm |
| Electrical Parameters (IEC/UL) | |
| Rated voltage (UL Group B) | 300V |
| Rated current (UL Group B) | 30A |
| Rated voltage (IEC) | 630V |
| Rated current (IEC) | 41A |
| Rated surge voltage | 6KV |
| Item Properties | |
| Connection method | Spring-cage connection |
| Pitch | 7.5mm |
| Number of potentials | 3 |
| Connection direction | 45° |
